Lumin P1 Mini Versatility Built inÂ
Builds on the success of the multi-award-winning LUMIN P1 by packing as much of the componentry and flexibility as possible into a new compact chassis.Â
Just like its bigger brother, P1 Mini is designed to be used as a streamer, a DAC, a pre-amplifier or all three!
With 5 analogue and digital inputs, a linear power supply and many other components taken from flagship players, LUMIN P1 Mini packs incredible versatility and value into its new slim chassis.
X1 Heritage
LUMIN P1 Mini takes many flagship features from the outstanding LUMIN X1:
FIBRE NETWORKING
A world-first on X1 and now featured on many LUMIN models, optical networking provides complete isolation from network noise. Additionally, dual network ports mean that you can connect Lor a NAS directly to P1 Mini.
FEMTO CLOCKING SYSTEM
P1 includes dual Femto crystal oscillators and our proprietary FPGA clock distribution system first debuted in X1.
 digital & analogue inputs
Versatile enough for any audio or video stereo system:
USB
- Industry-leading XMOS USB audio controller
- Native DSD512 and PCM384 compatible
- Windows 10 & Mac OS compatibility
ANALOGUE
- Stereo analogue input
- Passthrough function for home cinema integration with custom naming functionaity
SPDIF OPTICAL & RCA
- DoP64 / 192 kHz 24-bit compatible
- TOSLINK & SPDIF (RCA)
HDMI
- HDMI 2.0 Specification compatible
- Supports 2.0 PCM audio decoding
- HDR, Dolby Vision, Dolby Atmos, DTS passthrough
- ARC compatible output
Main features
- Five inputs including USB, HDMI, SPDIF and Analogue
- HDMI with stereo input + AV Passthrough & ARC
- Dual DAC ES9028PRO
- DSD512 & PCM384
- Femto Clock System with precision FPGA distribution
- New internal toroidal linear power supply
- Dual Network with Optical Fibre Network support
- Â lossless volume control
Flexible setup options
Use as a streamer, a DAC, a pre-amplifier or all three!
IDEA 1Â - STREAMING DAC
LUMIN P1 Mini can be used like all other LUMIN players. With its DSD512/PCM384 support, Femto Clock System, Fibre Networking, toroidal power supply, and Leedh Processing, it's packed with incredible components.
IDEA 2Â - HI-FI HUB
Connect all your stereo sources to LUMIN P1 Mini and attach a power amplifier and you've got everything you need for an incredible music system.
IDEA 3Â - 2-CHANNEL TV SYSTEM
No need for an AV Receiver. Simply attach your HDMI sources to your TV and P1 Mini to your TV. With HDMI ARC, all your audio comes through your main speakers.
SPECIFICATION
P1 MINI SPECIFICATION HIGHLIGHTS
- NETWORK PLAYBACK:
- Up to DSD512
- Up to 384 kHz, 16â32-bit, Stereo
- MQA Full Decoding
- UPSAMPLING RATES & BIT DEPTHS:
- DSD128 upsampling option for all files
- PCM 384kHz upsampling option for all files
- DIGITAL INPUT:
- USB:
- USB Audio Class 2 Compatible
- WINDOWS 10 (Release 1703 or above) / Mac OSX or above
- DoP 128 support
- PCM 44.1â384 kHz, 16 / 32-bit, Stereo
- OPTICAL/SPDIF:
- PCM 44.1 kHzâ192 kHz, 16â24-bit
- DSD64 (DoP64, DSD over PCM)
- HDMI:
- PCM 2.0 Audio support
- 4K Video Passthrough
- DIGITAL OUTPUT:
- USB:
- Native DSD512 support
- PCM 44.1â384 kHz, 16â32-bit, Stereo
- BNC SPDIF:
- PCM 44.1 kHzâ192 kHz, 16â24-bit
- DSD64 (DoP64, DSD over PCM)
- HDMI:(HDMI PASSTHROUGH AND ARC SUPPORT)
- PCM 2.0 Audio support
- 4K Video Passthrough
- ARC (Audio Return Channel) support
- ANALOGUE INPUT:
- ANALOG OUTPUT:
- Dual ESS SABRE32Â ES9028Pro DAC chips
- Fully balanced layout with high-quality components
- Femto Clock System with precision FPGA distribution
- OPTICAL NETWORK:
- Industry-standard Gigabit SFP
- 1000Base-T Gigabit Ethernet
- Adapter may be needed for your particular switch/cables
- Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN L1 or NAS)
- POWER SUPPLY:
- Internal toroidal linear
- Low-noise linear regulator
- PHYSICAL:
- FINISH:
- Black anodised aluminium
- Raw anodised aluminium
LUMIN (SOLID ALUMINIUM CHASSIS):- 400mm (W), 314mm (D), 77mm (H), 7kg
