Giving new life to digital sources A new command center, opening up your listening experience to the future
As high-resolution music distribution and high-quality audio streaming services become more commonplace, LUXMAN unveils our new USB equipped D/A converter, the DA-07X, fully compatible with todayâs diversifying digital music ecosystem. In order to competently handle current digital sources, LUXMAN has combined cutting-edge digital circuitry with our advanced analog audio technology know how. The DA-07X is a core component that breathes musicality and new life into digital audio reproduction and serves as a command center for modern audio systems as we move further into a new era.
| Type | 2 channel USB D/A converter |
|---|
| Supported sampling frequency | USB input (PCM) : 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 352.8 kHz, 384 kHz, 705.6 kHz, 768 kHz (16, 24, 32-bit)
USB input (DSD) : 2.8 MHz, 5.6 MHz, 11.2 MHz, 22.5 MHz (1-bit)
Coaxial / Optical / AES/EBU input : 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz (16, 20, 24-bit) |
|---|
| Analog ouput voltage / impedance | Unbalanced : 2.4 V / 300 Ω, Balanced : 2.4 V / 600 Ω
DSD format : 2.3 V |
|---|
| Frequency response | 5 Hz to 20 kHz (+0, -0.4 dB), 5 Hz to 47 kHz (+0, -3.0 dB) |
|---|
| Total harmonic distortion | Unbalanced : 0.001 %, Balanced : 0.001 % |
|---|
| S/N ratio (IHF-A) | 124 dB |
|---|
| D/A converter | ROHM BD34301EKV (monaural mode) x 2 |
|---|
| Power supply | 230 Vï½(50 Hz) / 115 Vï½ (60 Hz) |
|---|
| Power consumption | 21 W |
|---|
| External dimensions | 440(W) x 92(H) x 402(D) mm
front side knob of 14 mm and rear side terminal of 8 mm included in depth |
|---|
| Net weight | 12.8 kg (main unit) |
|---|
| Accessories | Power cable |
|---|
* LUXMAN Audio Player (Windows 10 and macOS 10.15) and driver software for Windows can be downloaded from the LUXMAN website.
* Apple, Mac, Mac OS, OS X, macOS and Macintosh are trademarks of Apple Inc., registered in the U.S. and other countries.
* Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and other countries.
* Sound Wave Logo is a registered trade mark of MQA Limited. ©2018
* MQA is a registered trade mark of MQA Limited. ©2018
* MQA-CD is a registered trade mark of MQA Limited. ©2017
* Bulk Pet is a registered trademark of Interface Co., Ltd.
