Designed in honor of our L-505 amplifier, which continues to fascinate many audio enthusiasts as possibly our most familiar hi-fi model and equipped with our newly developed âLIFESâ amplifier feedback engine, which is at the core of LUXMANâs contemporary designs, we would like to complete the Z series circle with the L-505Z. While inheriting all the high-quality sound and design know-how from our higher-end models, it has achieved even more as a multifunctional integrated amplifier. Redefining the standard and now entering a new era, the L-505Z invites you into the world of exciting high-end audio.
| Rated output | 100W + 100W (8Ω),
150W + 150W (4Ω) |
|---|
Input sensitivity/
input impedance | PHONO (MM): 2.5mV/47kΩ
PHONO (MC): 0.3mV/100Ω
LINE: 180mV/47kΩ
BAL.LINE: 180mV/55kΩ
MAIN IN: 1V/47kΩ |
|---|
| Output voltage | PRE OUT: 1V |
|---|
| Frequency response | PHONO: 20Hz to 20kHz (±0.5dB)
LINE: 20Hz to 100kHz (within -3dB) |
|---|
| Total harmonic distortion | 0.009% or less (8Ω, 1kHz)
0.09% or less (8Ω, 20Hz to 20kHz) |
|---|
| S/N ratio (IHF-A) | PHONO (MM): 87dB or more
PHONO (MC): 70dB or more
LINE: 104dB or more |
|---|
| Volume adjustment | LECUA |
|---|
| Amplification feedback circuit | LIFES 1.0 |
|---|
| Output configuration | Bipolar parallel push-pull |
|---|
| Damping factor | 200 |
|---|
| Max. amount of tone control | BASS: ±8dB at 100Hz
TREBLE: ±8dB at 10kHz |
|---|
| Power supply | 230V~(50Hz) / 115V~(60Hz) |
|---|
| Power consumption | 330W
90W (under no signal), 0.5W (at standby) |
|---|
| External dimensions | 440(W) x 178(H) x 454(D) mm
front side knob of 20mm and rear side terminal
of 27mm included in depth |
|---|
| Net weight | 22.5kg (main unit) |
|---|
| Accessories | Remote control (RA-17A)
Power cable |
|---|
Speaker terminal
Supported Y-lug terminal
dimension | Width of part a: 15mm or less
Width of part b: 8mm or more* Connection may not be performed depending on the shape of the Y-lug terminal. |
|---|
