560w into 8Ω
>-103dB Signal to Noise Ratio
Class AB Sliding Bias
HF Switch Mode Power Supply
Proprietary Chord MOSFETs
Fully Balanced Circuitry
Convection Cooled
Stereo Balanced XLR Inputs
Stereo Unbalanced RCA Inputs
12v Trigger Input
Included Top Light Ring
Solid Aluminium Chassis
Output Power:
560w RMS per channel @ 0.05% distortion into 8Ω
Frequency Response:
-1dB – 0.2Hz to 46kHz
Signal to Noise Ratio:
Better than -103dB
Channel Separation:
Better than 95dB
Input Impedance:
100kΩ Unbalanced/Balanced
Input Capacitance:
<30pf
Output Inductance:
2.6μH
Slew Rate:
70v per μS 1kHz, 20v Square Wave
Gain:
30dB
Stability:
Unconditional
Dimensions Without Integra Legs:
440mm (w) x 400mm (d) x 270mm (h)
Dimensions With Included Integra Legs:
500mm (w) x 400mm (d) x 310mm (h)
Weight:
45kG
